Dimenzije in katalog cevi za cevi so enake pri različnih dobaviteljih.
Material Vrste cevnih armatur, kot so nerjaveče jeklo, medenina in plastika.
Velika Britanija in ZDA Uporaba cevi za navojne cevi BSPP v armaturnih cevnih armaturah in priboru za industrijske cevi.
Priključki za pritrditev cevi BSP na vtičnico, NPT moški, SAE ORB, BSPT moški, ORFS moški, cevni konektor DIN 2353, metrični o-obroček itd.
Oblika BSPP cevnega adapterja, kot so naravnost, komolec, Tee, križ, reduktor.
Prav tako lahko dobavimo do 2 palčna bsp oprema.
7B-S BSP FEMALE / BSP FEMALE 60 ° CONE tabela velikosti cevi kot sledi:
PAR T NE | TRI D | D I MENS I ON S | |||||
E | F | B | L | S 1 | S 2 | ||
7B-02 S | G1 / 8 " X2 8 | G1 / 8 " X2 8 | 3 . 5 | 2 9 | 1 4 | 1 4 | |
7B-04 S | G1 / 4 " X1 9 | G1 / 4 " X1 9 | 5 . 5 | 3 2 | 1 9 | 1 9 | |
7B-04-06 S | G1 / 4 " X1 9 | G3 / 8 " X1 9 | 6 . 3 | 33 . 5 | 1 9 | 2 2 | |
7B-06 S | G3 / 8 " X1 9 | G3 / 8 " X1 9 | 6 . 3 | 36 . 5 | 2 2 | 2 2 | |
7B-06-04 S | G3 / 8 " X1 9 | G1 / 4 " X1 9 | 5 . 5 | 3 5 | 2 2 | 1 9 | |
7B-06-08 S | G3 / 8 " X1 9 | G1 / 2 " X1 4 | 7 . 5 | 3 8 | 2 2 | 2 7 | |
7B-08-06 S | G1 / 2 " X1 4 | G3 / 8 " X1 9 | 6 . 3 | 41 . 5 | 2 7 | 2 2 | |
7B-08 S | G1 / 2 " X1 4 | G1 / 2 " X1 4 | 7 . 5 | 4 2 | 2 7 | 2 7 | |
7B-08-10 S | G1 / 2 " X1 4 | G5 / 8 " X1 4 | 9 . 5 | 43 . 5 | 2 7 | 3 0 | |
7B-08-12 S | G1 / 2 " X1 4 | G3 / 4 " X1 4 | 10 . 9 | 4 4 | 2 7 | 3 2 | |
7B-10-08 S | G5 / 8 " X1 4 | G1 / 2 " X1 4 | 7 . 5 | 4 4 | 3 0 | 2 7 | |
7B-12-08 S | G3 / 4 " X1 4 | G1 / 2 " X1 4 | 7 . 5 | 44 . 5 | 3 6 | 2 7 | |
7B-12 S | G3 / 4 " X1 4 | G3 / 4 " X1 4 | 10 . 9 | 45 . 5 | 3 2 | 3 2 | |
7B-12-16 S | G3 / 4 " X1 4 | G1 " X1 1 | 11 . 7 | 4 7 | 3 6 | 4 1 | |
7B-16-12 S | G1 " X1 1 | G3 / 4 " X1 4 | 10 . 9 | 5 0 | 4 1 | 3 2 | |
7B-16 S | G1 " X1 1 | G1 " X1 1 | 11 . 7 | 51 . 5 | 4 1 | 4 1 | |
7B-20 S | G1 . 1/4 " X1 1 | G1 . 1/4 " X1 1 | 1 1 | 55 . 5 | 5 0 | 5 0 | |
7B-24 S | G1 . 1/2 " X1 1 | G1 . 1/2 " X1 1 | 1 3 | 57 . 5 | 5 5 | 5 5 | |
7B-32 S | G2 " X1 1 | G2 " X1 1 | 1 6 | 6 2 | 7 0 | 7 0 | |
