Kategorija izdelkov: Hidravlični adapterji JIC za cevno povezavo s tekočino
Standard izdelka: ISO 8434-2, SAE J514.
Material: ogljikovo jeklo, nerjavno jeklo ali bakrene zlitine.
Konec cevi JIC na druge končne povezave, kot sledi: Zapiralni pokrov BSP E, G, H, pribor serije ISO 6149, fitingi JIS B2351, fitingi ISO 11926 in SAE J1926 ORB, okovje DIN 3852 in ISO 1179, fitingi ISO 9974 itd.
1JB-OR / WD JIC MALE 74 ° CONE Z O-RING / BSP MALE CAPTIVE SEAL Dimenzijski grafikon:
DEL ŠT. | NIT | O-RING KAPTIVNO | DIMENZIJE | ||||||
E | F | E | F | A | B | L | S1 | ||
1JB-08-04OR / WD | 3/4 "X16 | G1 / 4 "X19 | 9.5X0.8 | WD-B04 | 16.7 | 12 | 37 | 22 | |
1JB-08-06OR / WD | 3/4 "X16 | G3 / 8 "X19 | 9.5X0.8 | WD-B06 | 16.7 | 12 | 37.5 | 22 | |
1JB-08OR / WD | 3/4 "X16 | G1 / 2 "X14 | 9.5X0.8 | WD-B08 | 16.7 | 14 | 43.5 | 27 | |
1JB-08-12OW / WD | 3/4 "X16 | G14 / 4 "X14 | 9.5X0.8 | WD-B12 | 16.7 | 16 | 45 | 32 | |
1JB-10-06OR / WD | 7/8 "X14 | G3 / 8 "X19 | 13X1 | WD-B06 | 19.3 | 12 | 41.5 | 24 | |
1JB-10-08OR / WD | 7/8 "X14 | G1 / 2 "X14 | 13X1 | WD-B08 | 19.3 | 14 | 46.5 | 27 | |
1JB-10-12OR / WD | 7/8 "X14 | G14 / 4 "X14 | 13X1 | WD-B12 | 19.3 | 16 | 47.5 | 32 | |
1JB-12OR / WD | 1,1 / 16 "X12 | G14 / 4 "X14 | 17X1 | WD-B12 | 21.9 | 16 | 50 | 32 | |
1JB-12-06OR / WD | 1,1 / 16 "X12 | G3 / 8 "X19 | 17X1 | WD-B06 | 21.9 | 12 | 46 | 30 | |
1JB-12-08OR / WD | 1,1 / 16 "X12 | G1 / 2 "X14 | 17X1 | WD-B08 | 21.9 | 14 | 48.5 | 30 | |
1JB-12-16OR / WD | 1,1 / 16 "X12 | G1 "X11 | 17X1 | WD-B16 | 21.9 | 18 | 56 | 41 | |
1JB-12-20OR / WD | 1,1 / 16 "X12 | G1.1 / 4 "X11 | 17X1 | WD-B20 | 21.9 | 20 | 60 | 50 | |
1JB-16OR / WD | 1,5 / 16 "X12 | G1 "X11 | 22X1.5 | WD-B16 | 23.1 | 18 | 57 | 41 | |
1JB-16-12OR / WD | 1,5 / 16 "X12 | G14 / 4 "X14 | 22X1.5 | WD-B12 | 23.1 | 16 | 53 | 36 | |
1JB-16-20OR / WD | 1,5 / 16 "X12 | G1.1 / 4 "X11 | 22X1.5 | WD-B20 | 23.1 | 20 | 61 | 50 | |
1JB-20OR / WD | 1,5 / 8 "X12 | G1.1 / 4 "X11 | 28X1.5 | WD-B20 | 24.3 | 20 | 62 | 50 | |
1JB-20-16OR / WD | 1,5 / 8 "X12 | G1 "X11 | 28X1.5 | WD-B16 | 24.3 | 18 | 58 | 46 | |
1JB-20-24OR / WD | 1,5 / 8 "X12 | G1.1 / 2 "X11 | 28X1.5 | WD-B24 | 24.3 | 22 | 64 | 55 | |
1JB-24OR / WD | 1,7 / 8 "X12 | G1.1 / 2 "X11 | 35X1.5 | WD-B24 | 27.5 | 22 | 67.5 | 55 | |
1JB-24-20OR / WD | 1,7 / 8 "X12 | G1.1 / 4 "X11 | 35X1.5 | WD-B20 | 27.5 | 20 | 65.5 | 50 | |
1JB-32OR / WD | 2,1 / 2 "X12 | G / 2 "X11 | 48X2 | WD-B32 | 34 | 20 | 73 | 75 | |
