Kategorija izdelka: SAE 37 deg
Material: ogljikovo jeklo, nerjavno jeklo ali bakrene zlitine
2NJ9 90 ° NPT MOŠKI / JIC FEMALE 74 ° SED. Dimenzijski grafikon:
PAR T NE | TRI D | DIMENZIJA S | |||||
E | F | A | B | S 1 | S 2 | ||
2NJ9-02-0 4 | Z1 / 4 "X1 8 | 7/16 "X2 0 | 2 1 | 9 | 1 1 | 1 7 | |
2NJ9-02-0 5 | Z1 / 4 "X1 8 | 1/2 "X2 0 | 2 1 | 9 | 1 1 | 1 7 | |
2NJ9-0 4 | Z1 / 4 "X1 8 | 7/16 "X2 0 | 25. 5 | 9 | 1 4 | 1 7 | |
2NJ9-04-0 6 | Z1 / 4 "X1 8 | 9/16 "X1 8 | 25. 5 | 10. 5 | 1 4 | 1 9 | |
2NJ9-0 6 | Z3 / 8 "X1 8 | 9/16 "X1 8 | 3 1 | 10. 5 | 1 9 | 1 9 | |
2NJ9-06-0 8 | Z3 / 8 "X1 8 | 3/4 "X1 6 | 3 1 | 10. 5 | 1 9 | 2 4 | |
2NJ9-0 8 | Z1 / 2 "X1 4 | 3/4 "X1 6 | 37. 3 | 10. 5 | 2 2 | 2 4 | |
2NJ9-08-1 0 | Z1 / 2 "X1 4 | 7/8 "X1 4 | 37. 3 | 1 2 | 2 2 | 2 7 | |
2NJ9-08-1 2 | Z1 / 2 "X1 4 | 1,1 / 16 "X1 2 | 37. 5 | 1 5 | 2 4 | 3 2 | |
2NJ9-1 2 | Z3 / 4 "X1 4 | 1,1 / 16 "X1 2 | 4 4 | 1 5 | 2 7 | 3 2 | |
2NJ9-12-0 8 | Z3 / 4 "X1 4 | 3/4 "X1 6 | 43. 5 | 10. 5 | 2 7 | 2 4 | |
2NJ9-12-1 0 | Z3 / 4 "X1 4 | 7/8 "X1 4 | 43. 5 | 1 2 | 2 7 | 2 7 | |
2NJ9-1 6 | Z1 "X11. 5 | 1,5 / 16 "X1 2 | 5 0 | 1 6 | 3 3 | 4 1 | |
2NJ9-16-1 4 | Z1 "X11. 5 | 1,3 / 16 "X1 2 | 4 9 | 1 5 | 3 3 | 3 6 | |
2NJ9-2 0 | Z1.1 / 4 "X11. 5 | 1,5 / 8 "X1 2 | 5 3 | 1 7 | 4 1 | 5 0 | |
2NJ9-2 4 | Z1.1 / 2 "X11. 5 | 1,7 / 8 "X1 2 | 5 9 | 2 0 | 4 8 | 5 5 | |
